ESF8B Vibratory Hammer

ESF 8B size vibratory hammer is attached to 30-35 tons class excavators. It is capable to drive steel sheet piles and steel tubes up to 12 meters in normal soft ground formations.

Excavator Class	38-40 tons
Centrifugal Force	464 kN
Eccentric Moment	8 kgm
Speed	2300 rpm
Pulling Force	150 kN
Push Down	90 kN
Total Weight (incl. Clamp)	1610 kg
Dynamic Weight (incl. Clamp)	1290 kg
Amplitute	13 mm
Power	148 kW
Displacement	253 liter/min
Working Pressure	350 bar
Height	1750 mm
Width	641 mm
Length	1130 mm
